Energy Storage System
▲Intelligent liquid-cooled temperature control refined constant temperature control management;
▲PCs and battery systems have two independent water systems;
▲High power density,small size;
▲Modular pre-installation design;
▲Pack level+whole box fire protection;
▲4G, WIFI and Ethernet onlne intelligent monitoring.
1、Intelligent liquid-cooled temperature control refined constant temperature control management,small elltemperature difference and long life;
2、PCs and battery systems have two independent water systems to ensure systemofficlency and rediscover presumption;
3、High power density,small size,low load occupation and eivilcanstruction costs;
4、Modular pre-installation design,which can be transported as a whole without on-site battery installation work;
5、Pack level+whole box fire protection,perfluorohexanone rapid fire extinguishing,high safety and reliability;
6、4G, WIFI and Ethernet onlne intelligent monitoring, remote inspection, reducing on-site manual inspection tasks.
Product Model | SRM-E2236-1260K-690-A | |
| DC Battery | Cell type | LFP 280Ah |
Battery Pack Capacity and Configuration | 14..336kWh/1P16S | |
Battery capacity and Pack quantity | 2236kWh/6x8 | |
Battery voltage range | 1165V~1498V | |
Charge and discharge rate | 1248 | |
Discharge depth | ≤0.5C | |
Cycles | 95%DOD | |
Number of temperature checks | >8000 | |
| AC Side | AC rated power | 6*210kW |
| AC maximum power | 6*231kW | |
| AC current distortion rate | <3% | |
| DC component | <0.5%lpn | |
| System voltage format | 690V | |
Grid voltage range | 621VAC~760VAC | |
Power factor | -1~1 | |
| Rated grid frequency | 50Hz/60Hz | |
| System Parameters | Maximum system efficiency | ≥89% |
Operating temperature | -30~55℃(Derating when exceeding 40 degrees Celsius) | |
Relative humidity | 0~95%RH,No condensation | |
Dimensions(width x depth x height) | 6058×2438×2896mm | |
Weight | <30T | |
Cooling method | air-cooled | |
Protection level | lp54 | |
Noise | <70dB | |
Networking form | 4G/Wifi/Ethernet | |
